Material Of Boxes: | Corrugated Plastic Sheet | Frame Stripe: | Plastic Or Aluminum |
---|---|---|---|
Color Of Frame: | White Or Black For Plastic Frame | Customization: | Available |
Advantage: | Foldable | Printing: | Single Color Printing |
Highlight: | corrugated plastic storage boxes,corrugated plastic storage bins |
The corrugated plastic boxes are made from the fluted plastic sheets which have the hollow structure. The fluted plastic sheets are flexible but too soft to carry heavy items. To enhance the hardness of the corrugated plastic boxes, we add the plastic or the aluminum strips as the frames.
Normally, the framed corrugated plastic boxes are unfoldable which requires a lot of space to transport the empty boxes.
Our box has a unique design that is framed and foldable simultaneously. Furthermore, the boxes also the following advantages.
Stackable
Possible to classify boxes by different colors
reusable
Water & Moisture resistant
Durability
Fibre free
Low cost tooling
Customized design
With plastic handles for easily moving the boxes
The corrugated plastic sheets which are extruded from HDPP (high-density polypropylene) resin. The sheet has a similar corrugated structure as the paper cardboard, except that the flutes are rectangular as the pictures below. Due to this hollow construction, the sheet has a favorable feature of light-weight for boxes making.
Unlike the paper cardboard which loses its rigidity when absorbing the water, the corrugated polypropylene sheets are water and moist repellant which allow the boxes can be directly put into refrigerated storage houses, and not to worry about the condensate water. The boxes also can be washed with water to re-use for many times.
The general physical characteristics of the corrugated polypropylene sheet is as follows.
Thickness |
2mm |
3mm |
4mm |
5mm |
6mm |
7mm |
|
Density GSM |
300-600 |
350-800 |
600-1300 |
800-1500 |
900-1800 |
1000-2000 |
|
Color |
any color available |
any color available |
any color available |
any color available |
any color available |
any color available |
|
Surface Tension (dyne/cm) |
35 |
35 |
35 |
35 |
35 |
35 |
|
breaking strength |
along the flutes |
>160 N |
>170 N |
>190 N |
>200 N |
>210 N |
>220 N |
across the flutes |
>140 N |
>150 N |
>160 N |
>170 N |
>180 N |
>190 N |
|
ultimate elongation |
along the flutes |
150% |
150% |
150% |
190% |
190% |
190% |
across the flutes |
40% |
40% |
40% |
50% |
50% |
50% |
The boxes are customized products. We have been specializing the corrugated plastic boxes for many years, and can make the unique boxes according to your requirements.
You only need to tell us the box's color and size, the weight of the boxes to carry, we design the boxes to you.
